Description
Key Features & Benefits
- Programming by CPL Data
- Realtime SPC Charts
- Program Optimization
- OCR Recognition
- CAD Import Programming
- Large 22″ x 26″ Inspection
- 2.4 GHz PC and LCD Monitor
- Sturdy Stand-alone Platform
- Optional Bar Code Reader
- Optional Rework Station
Specifications | |
|---|---|
| Inspection Speed | .33 Sec./FOV |
| Height Accuracy | 1µm (0.00004”) |
| Gauge R&R | <<10% (+/- 40% Tolerance) |
| Z Resolution | 1.78 µm (,00007”) |
| Lateral Resolution (X-Y) | 8µm (.003”) |
| Minimum Paste Deposit | 51µm (.002”) |
