Description
Key Features & Benefits
- Multiple Sensor Options: SP3D & PSI
- Automated Height, Area, Volume, Offset
- Gerber Programming & Auto-Scripting
- Defect Error Review
- Built-in Data and SPC Charting
- Color 3D Profiles of Measured Features
- ASCan Ultra Measurement Software
- Dell® PC and Windows® 10/11 Pro OS
- 20″ x 20″ Board Support
- 14″ x 20″ Max Board Inspection Area
- NIST Traceable Standard
- Hardware/Software Reference and Online Help
Specifications |
|
---|---|
Inspection Speed | .33 Sec./FOV |
Height Accuracy | 1µm (0.04 mils) |
Gauge R&R | <<10% (+/- 40% Tolerance) |
Z Resolution | .48 µm (.019 mils) |
Lateral Resolution (X-Y) | 6.8µm (.27 mils) |
Minimum Paste Deposit | 51µm (2 mils) |
