The multi-award winning QX500™ embraces CyberOptics unique image acquisition solution – Strobed Inspection Module (SIM) and is capable of inspecting 01005 components and larger at 200cm²/sec, securely positioning itself as the fastest area-scanning Automated Optical Inspection system in the industry. The QX500™ uses white strobed lighting, that consists of dual fixed angle lighting providing a superb image for defect review. You can further enhance component features by choosing a combination of lighting. QX500™ is designed to provide the IDEAL platform that can be integrated in assembly lines which manufacture memory modules, notebook PCS, mobile phones, automotive products, and other industrial electronic assemblies.
The QX600™ is designed with an all-new SIM (Strobed Inspection Module) with enhanced illumination – delivering the best 01005 and solder joint inspection performance ever. With a higher sensor resolution (12 µm), you get to see crisp, perfect quality images for more accurate defect review. QX600 is equipped with SAM (Statistical Appearance Modeling) vision technology to give you the power to inspect ‘anything’ while keeping programming extremely simple – no algorithms to tune or parameters to adjust. SAM works in perfect harmony with AI² (Autonomous Image Interpretation) technology to enable fast programming and reliable discrimination against defects.
CyberOptics is the world’s number-one supplier of solder paste inspection equipment used to monitor and control one of the most crucial steps affecting the finished quality of circuit boards. Solder paste deposition is the key process in board assembly operations using SMT techniques. Our LSM™ system was the industry’s first popular method of manually inspecting solder paste; our SE systems revolutionized SMT production by offering an automated method for performing in-process inspection on the assembly line. With more than 3000 systems installed worldwide, CyberOptics has the largest installed base of solder paste inspection equipment in the industry. See for yourself why CyberOptics is #1 in 3D solder paste inspection technology.
CyberOptics is the world’s number-one supplier of solder paste inspection equipment used to monitor and control one of the most crucial steps affecting the finished quality of circuit boards. Solder paste deposition is the key process in board assembly operations using SMT techniques. Our LSM™ system was the industry’s first popular method of manually inspecting solder paste; our SE systems revolutionized SMT production by offering an automated method for performing in-process inspection on the assembly line. With more than 3000 systems installed worldwide, CyberOptics has the largest installed base of solder paste inspection equipment in the industry. See for yourself why CyberOptics is #1 in 3D solder paste inspection technology.
CyberOptics is the world’s number-one supplier of solder paste inspection equipment used to monitor and control one of the most crucial steps affecting the finished quality of circuit boards. Solder paste deposition is the key process in board assembly operations using SMT techniques. Our LSM™ system was the industry’s first popular method of manually inspecting solder paste; our SE systems revolutionized SMT production by offering an automated method for performing in-process inspection on the assembly line. With more than 3000 systems installed worldwide, CyberOptics has the largest installed base of solder paste inspection equipment in the industry. See for yourself why CyberOptics is #1 in 3D solder paste inspection technology.
The CyberOptics SE500, an advanced 100% 3D solder paste inspection system which re-defines inspection speed. This system has the ability to inspect the most demanding assemblies with a >70 cm2/second inspection speed that does not compromise measurement accuracy and repeatability. Building on CyberOptics’ reputation as the provider of solder paste inspection systems with industry-leading volume accuracy, the SE500 can inspect pad sizes down to 01005 component size (150µm x 150µm) while keeping up with ever-increasing line speeds. The SE500 product line has two models that accommodate different panel sizes. The SE500 features a conveyor that can transport panels from 50mm x 50mm (2in x 2in) up to 510mm x 510mm (20in x 20in). The SE500X can transport panels from 100mm x 100mm (4in x 4in) up to 810mm x 610mm (32in x 24in).
The SE600™ – CyberOptics’ flagship SPI system, is the most advanced, high performance system ever. SE600™ brings together best accuracy and world-class usability on a single platform – making it the most ideal inspection solution for automotive, medical, military and other top niche markets.SE600™ comes with a standard dual illumination sensor designed to offer the best GR&R results – even on the very smallest of paste deposits. The award-winning new SPIV5 software offers revolutionary features that enable incredibly smarter and faster inspection.
The LaserVision SP3D combines laser measurement accuracy with Automatic Data Collection (ADC) for real-time control of SMT stencil printing. With its Windows® interface, the SP3D is easy to learn and use, making it an exceptional value for the SMT manufacturer concerned with improving printing and production yields.
The LineMaster DMi is a revolutionary dual-mode 3D SPI and AOI offline platform combining the best of ASC International’s 3D SPI sensor technology with its sophisticated image / algorithm-based (Modeling) AOI sensor technology for the most comprehensive and value-packed inspection solution available today.
The LineMaster Falcon Plus AOI solution offered by ASC International provides manufacturers with a solid inline platform to validate the overall variables associated with component placement and post print inspection. State-of-the-art Detech2 Technology software detects attributes such as absence – presence, polarity, OCR, solder inspection and lead quality all with very low false call rates. The Falcon Plus provides a value proposition unmatched in the industry.
Call ASC today for a free consultation and onsite evaluation. A revolutionary inline platform combining the best of ASC International’s VisionPro Merlin sophisticated image and algorithm-based AOI sensor technology into an affordable inline solution.
The MSS 130 Digital Video Inspection Scope includes plug-and-play to any computer system, a multiple Image tool for image enhancement and clarity, and a measurement tool for shapes such as line, circle, angle, center point, and arc. It works with a variety of lenses and lighting which are fully controllable. It can also be networked with multiple digital scopes.
