Description
Key Features & Benefits
- Fully Automated Height/Volume Measurements
- Integrated SPC Run Charts and Data Reports
- Color 3D Profiles of Measured Features
- Windows® 7 Pro / 10 Pro OS
- Two-Year, End-User Warranty
- VisionPro 3D Sensor
- Dell® PC and LCD Monitor
- 18″ x 22″ (450 mm x 550 mm) Inspection
- Optional NIST Calibration Standard
- Hardware/Software Reference Guides
Specifications |
|
---|---|
Inspection Speed | .33 Sec./FOV |
Height Accuracy | 1µm (0.04 mils) |
Gauge R&R | <<10% (+/- 40% Tolerance) |
Z Resolution | .48 µm (.019 mils) |
Lateral Resolution (X-Y) | 6.8µm (.27 mils) |
Minimum Paste Deposit | 51µm (2 Mils) |
